Seat Leon >> Central locking button
The vehicle can be locked and unlocked from the inside using the central locking button.
Fig. 59 Detail of rear left door central locking button
Locking the vehicle
– Press the button
.
Unlocking the doors
– Press the button .
The central locking button is still operative when the ignition is switched off.
Except, if the "safe" security system is activated.
Please note the following when you use the central locking button to lock your vehicle:
• It will not be possible to open the doors or the tailgate from the outside
(this may offer extra safety, for instance when stopped at traffic lights).
• The driver and passenger doors cannot be locked if they are open. This
prevents you from locking yourself out of the vehicle.
• Repeated operation of the central locking will deactivate the central
locking button for 30 seconds. Once this time has passed, the button may be
used once more.
• There is a danger that the key may remain inside the vehicle, if the vehicle
is locked using the central locking button when the driver's door is closed
and, for example, the passenger door open. If this door is closed, then the
keys will remain inside the vehicle.
• All doors may be locked separately from inside the car. Do this by pulling
the door release lever once.
WARNING
• If the vehicle is locked, children and disabled people may be trapped
inside.
• The central locking button is not operative in the following cases.
• When the vehicle is locked from the outside (using the remote or the
key).
• While the ignition is not activated after unlocking the door lock cylinder
with the key.
Note
• Vehicle locked, button amber
colour
• Vehicle unlocked, button red.
